Camouflage Patterns

Painting masks for the non-insignia elements of an aircraft's camouflage scheme.

17 files

  1. Hello!

    I've created a "smoke ring" for the Italian camouflage in 1/48 scale.
    Have fun crafting!

    Harry
    • 5 Downloads
    Updated
  2. I've created some camo splinter masks for the 1/32 Ju87D/G series. Used the kit supplied masking details as a template to create them. Haven't tried it out yet, so "buyer beware"😉
    • 9 Downloads
    Submitted
  3. Rear wing panel masks for the 70s and early 80s high vis US Navy F-14a

    Compatible with the Academy 1/72 F-14a (12563) or similar

    Tested on a Cricut Joy Xtra using Frisket clear masking film. Software may resize the item when you upload it, but should be 9.305cm wide by 4.026 cm high using outer contours

    This is the SVG file to be compatible with most cutting machines.

    This is also my first mask so let me know if you have any issues or suggestions.  Enjoy!


    • 3 Downloads
    Submitted
  4. This is my solution to replicate the rib tapes and stitching seen on biplanes with fabric-covered wings and also some monoplanes which still had fabric covered elevators, rudders etc such as the Hurricane shown in my photograph.
    • 18 Downloads
    Submitted
  5. My first post so go gentle!

    This is the Arma Hobby Paint Scheme A which Arma Hobby kindly made available as a PDF on their website https://armahobbynews.pl/en/blog/2019/01/03/masks-for-hurricane-models-pattern-a-and-b/.

    I will post the Scheme B once I have converted and tidied up. Hope you find it useful.
    • 56 Downloads
    Submitted
  6. This file is to help with positioning. Both were created in Inkscape - a great programme!
    • 57 Downloads
    Submitted
  7. Hi

    These masks are scaled in 1/48 for a Camo pattern late mark Spitfire. One file has the underlying images to aid positioning - the other file has just the cuts to be made

    Will
    • 71 Downloads
    Submitted
  8. Will make masking the white on the wings for the classic gull gray/white camouflage much easier.

    Designed for the Hasegawa kit, I cannot vouch for any fit with any other F-14 kit in 1/72

    Cheers,
    Hoops
    • 16 Downloads
    Submitted
  9. Hello, this pattern it's for the Hannover CL.II WingNut Wings 1/32.
    Michel
    • 41 Downloads
    Submitted
  10. this is the white flash  around the black exhaust trim seen on many FW 190  traced from the cutting edge decal sheet  originally in 1/32 will need to be resized to your purpose
    • 42 Downloads
    Submitted
  11. This is multiple file camouflage cutout pattern for the 1/32nd ZM Ki-45. All individual files cover a different part of the aircraft camouflage, including upper fuselage, both sides of the fuselage, horizontal stab and left and right wings.
    • 23 Downloads
    Submitted
  12. This is multiple file camouflage cutout pattern for the 1/32nd ZM Ki-45. All individual files cover a different part of the aircraft camouflage, including upper fuselage, both sides of the fuselage, horizontal stab and left and right wings.
    • 23 Downloads
    Submitted
  13. This is multiple file camouflage cutout pattern for the 1/32nd ZM Ki-45. All individual files cover a different part of the aircraft camouflage, including upper fuselage, both sides of the fuselage, horizontal stab and left and right wings.
    • 22 Downloads
    Submitted
  14. This is multiple file camouflage cutout pattern for the 1/32nd ZM Ki-45. All individual files cover a different part of the aircraft camouflage, including upper fuselage, both sides of the fuselage, horizontal stab and left and right wings.
    • 22 Downloads
    Submitted
  15. This is multiple file camouflage cutout pattern for the 1/32nd ZM Ki-45. All individual files cover a different part of the aircraft camouflage, including upper fuselage, both sides of the fuselage, horizontal stab and left and right wings.
    • 26 Downloads
    Submitted
  16. 15.000th Curtiss P-40N
    • 12 Downloads
    Submitted
  17. Stencil to create the wavy leading edge camo on late Luftwaffe Bf109's. Scaled to fit 1/32 Hasegawa kit
    • 62 Downloads
    Updated
